| Model No. |
VPP-ME 2010 |
VPP-ME 2515 |
| X Y Work Stage |
| Size of Top Plate |
404 x 228 mm |
450 x 280 mm |
| Traverse: X & Y axis |
200 x 100 mm |
250 x 150 mm |
| Load Capacity |
25 Kg |
| Z axis Travel |
150 mm |
| Base and column |
Made of cast Iron |
| Video System |
|
|
| Imaging Device |
1/3 CCD video camera |
| Lens |
High Resolution Tele-centric Zoom Lens |
| Magnification Range |
25x - 145x |
| Illumination System |
| Profile |
LED Array placed below |
| Surface |
Ring LED Brightness Manually controlled |
| Measurement System |
| Linear Measurement X Y Z Axis |
Linear Encoders 1 u LC |
| Measurement Software |
2D Measurement Software with Programming |
| SPC |
Facility to transfer to Excel and make reports |
| Measuring Accuracy |
(3 + L/100) microns |
| Computer |
Latest Computer with 17" LCD Monitor Windows XP OS |
| Optional Accessories |
0.5x and 2x Lens |
| Physical Specifications |
| Net Weight |
110 Kgs |
120 Kgs |
| Overall Dimensions |
700 x 600 x 900 mm |
